| Measurement Principle | Differential pressure (based on Bernoulli’s equation) |
|---|
| Body Material | SS304, SS316, Hastelloy C, Monel, or Carbon Steel |
|---|
| Plate Thickness | Typically, 3 mm to 12 mm |
|---|
| Bore Design | Concentric, Eccentric, or Segmental |
|---|
| Flow Range | Suitable for a wide range of flows |
|---|
| Accuracy | ±0.5% to ±1% of reading |
|---|
| Size Range | DN 15 to DN 1200 (½” to 48”) |
|---|
| Pressure Rating | Up to 250 bar |
|---|
| Temperature Range | -40°C to 400°C |
|---|
| Seal Material | PTFE, Graphite, or Metallic seals for high-temperature or aggressive media |
|---|
| Mounting Style | Between flanges or in carrier rings |
|---|
