Specifications
| Measurement Principle | Differential Pressure (based on Bernoulli’s equation) |
|---|---|
| Body Material | SS304, SS316, Cast Steel, or Carbon Steel |
| Accuracy | ±1% to ±2% of reading |
| Flow Range | 0.1 m/s to 30 m/s |
| Size Range | DN 25 to DN 6000 (1” to 240”) |
| Pressure Rating | Up to 100 bar |
| Temperature Range | -40°C to 250°C |
| Flange Standards | ANSI, DIN, or JIS standard flanges |
| Measurement Accuracy | ±1% of flow rate (depending on process conditions) |
| Installation Orientation | Horizontal or Vertical |
